Maintenance Free ( topping up not required )
Non - spillable ( no free acid )
Low Self Discharge, less than 3% per month
Both Vertical & Horizontal installations
Excellent High Rate performance, 30% higher power for 5 to 15min discharge
Absorbent Glass Mat technology for efficient gas recombination
Its design life is up to 6 years in floating application
Reliable Safety Valve in each cell
Constant power discharge characteristics at 25 oC/77 oF Unit: W | ||||||||||
Discharge F.V. Time (V/cell) |
3Min |
5 Min |
10 Min |
15 Min |
20 Min |
30 Min |
40 Min |
50 Min |
60 Min |
120 Min |
1.80V | 241 | 156.2 | 112.4 | 88.9 | 75.9 | 57.6 | 44.3 | 36.7 | 32.3 | 17.8 |
1.70V | 272 | 186.7 | 125.5 | 96.6 | 80.3 | 60.0 | 46.0 | 37.9 | 33.1 | 18.2 |
1.60V | 285 | 200.0 | 132.0 | 101.0 | 83.3 | 61.4 | 47.1 | 38.7 | 33.6 | 18.4 |
1.50V | 291 | 205.7 | 134.5 | 103.2 | 84.7 | 62.2 | 47.7 | 39.1 | 33.9 | 18.5 |
1.40V | 293 | 209.5 | 136.3 | 104.3 | 85.4 | 62.7 | 47.9 | 39.4 | 34.2 | 18.6 |
1.30V | 293 | 211.4 | 137.5 | 105.2 | 85.9 | 63.0 | 48.2 | 39.6 | 34.3 | 18.7 |
Constant current discharge characteristics at 25 oC/77 oF Unit: A | ||||||||||
Discharge F.V. Time (V/cell) |
3 Min |
5 Min |
10 Min |
15 Min |
20 Min |
30 Min |
40 Min |
50 Min |
60 Min |
120 Min |
1.80V | 21.1 | 14.2 | 9.9 | 7.69 | 6.56 | 4.88 | 3.73 | 3.07 | 2.70 | 1.48 |
1.70V | 24.3 | 17.0 | 11.0 | 8.36 | 6.94 | 5.09 | 3.87 | 3.17 | 2.76 | 1.52 |
1.60V | 25.6 | 18.2 | 11.6 | 8.74 | 7.21 | 5.20 | 3.96 | 3.24 | 2.80 | 1.53 |
1.50V | 26.2 | 18.7 | 11.8 | 8.93 | 7.32 | 5.27 | 4.01 | 3.27 | 2.83 | 1.54 |
1.40V | 26.5 | 19.1 | 12.0 | 9.03 | 7.39 | 5.31 | 4.03 | 3.30 | 2.85 | 1.55 |
1.30V | 26.5 | 19.2 | 12.1 | 9.10 | 7.43 | 5.34 | 4.06 | 3.32 | 2.86 | 1.56 |
